DS-2DE3A404IW-DE/W | HikVision DarkFighter IR Network Speed Dome

Camera

• Image Sensor1/2.5" Progressive Scan CMOS
• Min. IlluminationColor: 0.008 lux @(F1.2, AGC ON), 0.011 lux @(F1.4, AGC ON), 0 lux with IR
• Shutter Speed1/3 s to 1/100,000 s
• Slow Shutter Yes
• Wide Dynamic Range 120dB
• Day & Night IR Cut Filter
• Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°

Lens

• FocusAuto
• Lens Type2.8 to 12 mm，Motorized
• FOVHorizontal field of view: 114° to 32°;Vertical field of view: 59° to 18° ;Diagonal field of view: 141° to 36.5°
• ApertureF1.4
• Lens MountΦ14

Illuminator

• IR RangeUp to 30 m
• Wavelength850nm

Video

• Max. Resolution2688 × 1520
• Main Stream 50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
  60Hz: 30fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
• Sub Stream 50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
  60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
• Third Stream 50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288)
  60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
• Video Compression Main stream: H.265/H.264;Sub stream: H.265/H.264/MJPEG;Third stream: H.265/H.264
• Video Bit Rate 32 Kbps to 16 Mbps
• H.264 Type Main Profile/High Profile
• H.265 Type Main Profile
• H.264+ Main stream supports
• H.265+ Main stream supports
• Scalable Video Coding (SVC)Support H.264 and H.265 encoding
• Region of Interest (ROI)Support 1 fixed region for main stream and sub stream

Audio

• Environment Noise FilteringYes
• Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHZ/48kHz
• Audio Compression G.711/G.722.1/G.726/MP2L2/PCM
• Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)

Network

• Simultaneous Live ViewUp to 6 channels
• APIONVIF (PROFILE S, PROFILE G), ISAPI
• ProtocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
• User/HostUp to 32 users,3 levels: Administrator, Operator and User
• Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
• Network StorageSupport Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
• ClientiVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
• Web BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view: Chrome 45.0+, Firefox 52.0+
• Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error, Alarm input, Alarm output


• Day/Night SwitchDay/Night/Auto/Schedule/Triggered by Alarm In
• DNR3D DNR
• Image EnhancementBLC/3D DNR/HLC
• Image SettingsRotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser

Interface

• Audio1 input (line in, 3.5 mm), 1 output(3.5 mm), mono sound
• Alarm 1 input, 1 output (max. 12 VDC, 30 mA), terminal block
• Video Output1Vp-p composite output (75 Ω) (For adjustment only)
• On-board StorageBuilt-in Micro SD/SDHC/SDXC slot, up to 128 GB
• Hardware Reset Yes
• Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port

Event

• Basic Event Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
• Smart EventLine crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection
• Face Detection Yes
• Exception Detection Scene change detection

General

• Linkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
• Firmware VersionV5.5.80
• Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
• General Function Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
• Startup and Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
• Power Supply12 VDC ± 25%, PoE (802.3af),Terminal block for DC input
• Power Consumption and Current 12 VDC, 0.9 A, max. 10.5 W, PoE (802.3af, 36V to 57V), 0.4 A to 0.2 A, max. 12.5 W
• Camera Dimension Φ153.4 × 133.1 mm (Φ6" × 5.2")
• Camera Weight Camera: 1287 g (2.84 lb.)

Approval

• ProtectionIP66，IK10
